Product Overview

● Type: D

● Display unit (mm / inch): mm

● Application: External measurement

● Measuring span Mes: 20 mm

● Measuring range Meb: 0-20 mm

● Range of indication Azb: 0-20.5 mm

● Scale interval Skw: 0.01 mm

● Maximum permissible errors G: 0.03 mm

● Repeatability limit r: 0.01 mm

● Measuring force F minimum: 1.1 N

● Measuring force F maximum: 1.6 N

● Type of measuring contact movable: HM-Ball Ø 1.5 mm

● Measuring contact movable Hb: 24.7 mm

● Type of measuring contact fixed: HM-Ball Ø 1.5 mm

● Measuring contact fixed Hf: 24.6 mm

● Measuring contact thickness maximum: Ø 4 mm

● Measuring depth maximum L: 85 mm

● Weight: 210 g

● Reference temperature: 20 °C

● Operating temperature: 10 to 30 °C

● Storage temperature: -10 to 50 °C

● Protection class: IP65

OPTIONAL ACCESSORIES

● Wooden box: Order no. 1732-45

● Holding unit: Order no. 8004-50
